DLIMZI PRO F-1500 L3000W1500 Flatbed Trailer (Medium Duty)

Details :

Internal Dimensions :

3000 × 1500 mm

External Dimensions :

4380 × 1950 mm

Side Wall Height :

400 mm

Axle type:

1 × braked axle (leaf spring with shock absorbers)

Frame:

Hot-dip galvanized welded steel frame

Floor:

Waterproof anti-slip plywood

Gross Weight :

1500 kg

Unladen Weight :

approx. 305 kg

Payload:

1195 kg

Brakes:

Overrun braking system

Coupling:

50 mm standard EU coupling head

Plug Type:

13-pin (EU standard)

Tires:

185R14C 104N (2 x 900 kg)

Standard Equipment :

• Jockey wheel with clamp (heavy-duty) • Removable front and rear panels • Integrated lashing points (6 pcs) • Non-slip plywood floor • Full LED lighting system (rear + side markers) • Reflectors according to EU regulations

Description

A robust and professionally engineered flatbed trailer designed for demanding transport applications. The structure features precision-bent steel side panels and reinforced joints, ensuring excellent rigidity and long service life. The hot-dip galvanized steel frame provides superior corrosion resistance, while the waterproof plywood floor offers a slip-resistant surface for safe and reliable loading. The leaf spring suspension system with integrated shock absorption ensures stable handling and consistent performance, even under heavier loads
